Rocker rust!

Thread Tools

Search this Thread

Old Sep 13, 2013 | 09:12 PM
  #1
ObsoleteE's Avatar
Thread Starter
Senior Member

Joined: Nov 2011
Posts: 806
Likes: 22
From: Rochester, NY
Default Rocker rust!

I bought this truck less than 2 years ago, and it was rust free. For the past year I've been noticing a bit of rust on the rockers, and bottom door seams. Fast forward to a few weeks ago, I went off roading and must have flexed the truck too much, and my front driver and passenger rocker panels actually split. I know I can cut the rust out, and weld in new rockers, but I don't have access to a welder. Any other ideas here?

Old Sep 13, 2013 | 09:16 PM
  #2
Tackle's Avatar
Title

Joined: Sep 2012
Posts: 6,672
Likes: 499
From: USA
Default

Bring it to a shop is about your only other option. Or sell I suppose.

Cost of the welder and doing it yourself would cost about the same as a shop.
Old Sep 13, 2013 | 10:22 PM
  #3
2002FX4's Avatar
2003 FX4 Supercrew

Joined: Aug 2010
Posts: 732
Likes: 76
Default

Rust free huh? They're shot! I'm going to be replacing the rockers on a buddies expedition and we are going to use the 3M glue instead. I'm predicting it won't be that bad, but you know how that goes....
Old Mar 2, 2014 | 10:43 PM
  #4
ObsoleteE's Avatar
Thread Starter
Senior Member

Joined: Nov 2011
Posts: 806
Likes: 22
From: Rochester, NY
Default

Bump, I am going to tackle this job one way or another at the end of April. Either going to paint with POR15 and bed liner the bottom 2 inches of the cab, or cut all of the rust out, spray foam and then spray with bed liner. I do NOT have access to a welder, and I need to do this cheap. Rear corners are getting bad too, besides that, the truck is clean as hell. I've read that foam will act like a sponge, but if I spray everything with bed liner, won't it be sealed from the elements? I am also gonna remove the running boards to take any un needed stress off of the rockers.
Old Mar 3, 2014 | 08:14 AM
  #5
trixR4kids's Avatar
Senior Member

Joined: Jun 2013
Posts: 133
Likes: 23
From: Central PA
Default

I wouldn't foam anything. Chances of moisture getting in there are still pretty good and that spray foam will hold that water for a lot longer then if there was nothing in there at all.
Old Mar 3, 2014 | 04:49 PM
  #6
sportster07's Avatar
Senior Member

Joined: Sep 2013
Posts: 787
Likes: 72
From: New Brunswick/Alberta
Default

Buy some aftermarket panels, cut the old ones out and weld the new ones in. Primer them then take them to a shop, have the color matched and paint the whole thing one color. IMO it looks like crap and is super obvious what was done when the bottom section of a vehicle is black when the rest of the vehicle isn't. It looks like a cheap body job to me and someone who didn't want to spend the money to have it match.
Old Mar 3, 2014 | 05:20 PM
  #7
jollyroger331's Avatar
Senior Member

Joined: Apr 2012
Posts: 2,137
Likes: 160
From: Garden City MI
Default

That's typical, if you see a little rust on you rockers with these trucks the rocker is already gone. They rust from the inside out.
Old Mar 3, 2014 | 05:28 PM
  #8
iowaredneck's Avatar
Redneck engineerin'

Joined: Nov 2008
Posts: 1,336
Likes: 9
From: North Liberty, Iowa
Default

Very normal. Stupid engineers thought those little trim pieces would be nice on the inside but all they do is leak water and rust out the rockers

Last edited by iowaredneck; Mar 3, 2014 at 05:55 PM.
Old Mar 3, 2014 | 08:52 PM
  #9
ObsoleteE's Avatar
Thread Starter
Senior Member

Joined: Nov 2011
Posts: 806
Likes: 22
From: Rochester, NY
Default

Originally Posted by sportster07
Buy some aftermarket panels, cut the old ones out and weld the new ones in. Primer them then take them to a shop, have the color matched and paint the whole thing one color. IMO it looks like crap and is super obvious what was done when the bottom section of a vehicle is black when the rest of the vehicle isn't. It looks like a cheap body job to me and someone who didn't want to spend the money to have it match.
No access to a welder.
Old Mar 3, 2014 | 11:05 PM
  #10
ColdMonster's Avatar
Senior Member

Joined: Aug 2011
Posts: 507
Likes: 33
From: CA
Default

Cutting and filling with expanding foam will cause a lot more problems. It holds a lot of moisture, dirt, and surface rust in will rust out the rest of your rocker fast. The only proper way to do it is weld. The 2nd way is to use that 3m glue like 2002fx4 suggested. I've never used it but it should be fine for non structural parts. The 3rd option witch I don't recomend but will make it look good is cut out rust and fiberglass hole.
